Bi-Metal Thermometer
Features
- Scale Size: 5"
- Case: Stainless Steel
- Dial: Aluminum
- Accuracy: Within 1% of scale range
- Stem Assembly: 1/2" NPT
- Stem Length: 2.5", 4", 6", 9", and 12"
Longer stem lengths available
| Catalog # | Dial Size | Stem Type |
|---|---|---|
| 3BM | 3" | Rear |
| 5BM | 5" | Rear |
| 3VBM | 3" | Variable |
| 5VBM | 5" | Variable |
| Code | Stem Length |
|---|---|
| 25 | 2.5" |
| 4 | 4" |
| 6 | 6" |
| 9 | 9" |
| 12 | 12" |
| Dual Scale (both °F and °C) |
Scale |
|---|---|
| 0 to 250°F 32 to 121°C |
2°/1° |
| -50 to 400°F -45 to 204°C |
1°/1/2° |
| 0 to 400°F 32 to 204°C |
2°/1° |
| -80 to 100°F -62 to 37°C |
2°/1° |
| 0 to 550°F 32 to 287°C |
2°/1° |
|
How to Order
Example Product #: 3VBM-4-0-250F |
||
|---|---|---|
| Catalog Number | Stem Length | Temp Range |
| 3VBM | 12 | 0–250F |
